ROTOR DISC » RN1544V

Specification

Type
Vented
Outter Ø
283
Num. of holes
6
Disc Thickness (Max)
28
Height
38
Centering Diameter
100
Pitch Circle Ø
124
Front/Rear
Front
Structure Material
G3000
Drum Ø:
167
Disc Thickness (Min)
26

Cross Reference

NISSAN
40206-0W001
NISSAN
40206-1W200
NISSAN
40206-7Z000
NISSAN
40206-VE400
NISSAN
D0206-7Z00J-NW
OEM
5861186400
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.99~05.02 3000 ZD30DDTi ATE50 RN1544V PN2389 DN1296 FN1174
08.99~05.02 3000 ZD30DDTi ATWE50 RN1544V PN2389 DN1296 FN1174
05.97~08.99 3200 QD32ETi AVE50 RN1544V PN2389 DN1296 FN1174
05.97~08.99 3200 QD32ETi AVWE50 RN1544V PN2389 DN1296 FN1174
05.97~08.00 3300 VG33E ALE50 RN1544V PN2389 DN1296 FN1174
05.97~08.00 3300 VG33E ALWE50 RN1544V PN2389 DN1296 FN1174
08.00~05.02 3500 VQ35DE APE50 RN1544V PN2389 DN1296 FN1174
08.00~05.02 3500 VQ35DE APWE50 RN1544V PN2389 DN1296 FN1174
10.95~11.98 3300 VG33E R50 RN1226VRN1544V PN2389 DN1302 FN1189
09.95~02.99 2700 TD27-ETi PR50 RN1544V PN2389 DN1302 FN1189
08.96~02.99 3200 QD32ETi RR50 RN1544V PN2389 DN1302 FN1189
09.95~02.99 3300 VG33E LR50 RN1226VRN1544V PN2389 DN1302 FN1189
08.96~03.99 3200 QD32ETi JRR50 RN1544V PN2389 DN1302 FN1189
08.96~02.99 3300 VG33E JLR50 RN1544VRN1226V PN2389 DN1302 FN1189
05.99~01.05 2400 KA24DE WD22 RN1544V PN0372 FN1189
06.05~08.08 2800 WM28DTI WD22B RN1544V PN0372 DN1302 FN1189
05.03~06.05 2800 WM28TI WD22B RN1544V PN0372 DN1302 FN1189
05.99~01.05 3300 VG33E WD22 RN1544V PN0372 FN1189

Exemption from liability: the catalog data is advisory and can be used for reference only
