ROTOR DISC » RN1542V

RN1542V

Specification

Num. of holes
5
Front/Rear
Rear
Type
Vented
Outter Ø
278
Disc Thickness (Max)
18
Height
61.7
Centering Diameter
58
Pitch Circle Ø
100
Drum Ø:
169
Disc Thickness (Min)
16
Structure Material
G3000

Cross Reference

SUBARU
26700-SG000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUBARU   »   Forester

08.12~02.16 2000 EE20Z SJDC RHD RN1507V PN7499 RN1542V PN7803 FN0685
08.12~02.16 2000 EE20Z SJDD LHD RN1507V PN7499 RN1542V PN7803 FN0685
08.12~02.16 2000 FA20E SJG JPN RN1507V PN7499 RN1542V PN7803 FN0685
08.12~02.16 2000 FA20E SJG#KK8 RN1507V PN7499 RN1542V PN7803 FN0685
02.16~01.19 2000 FA20E SJG#KK8 RN1507V PN7499 RN1542V PN7803 FN0685
08.12~03.16 2000 FA20E SJGK85 RHD RN1507V PN7499 RN1542V PN7803 FN0685
03.16~01.19 2000 FA20E SJGK85 RHD RN1507V PN7499 RN1542V PN7803 FN0685
08.12~02.16 2000 FA20F SJGL85 RN1507V PN7499 RN1542V PN7803 FN0685
08.12~01.19 2000 FB20B SJ5#L7C RN1122VRN1507V PN7460PN7499 RN1659RN1542V PN7501PN7803 FN0685
