ROTOR DISC » RN34004
Specification
Type
Solid
Outter Ø
292
Num. of holes
5
Disc Thickness (Max)
12.5
Height
45
Centering Diameter
70.7
Pitch Circle Ø
115
Front/Rear
Rear
Drum Ø:
151
Disc Thickness (Min)
10
Structure Material
G3000
Cross Reference
GM
13502137
GM
13502138
GM
13502139
GM
23118061
GM
23118282
GM
95527033
OEM
569071
OPEL
05 69 075
OPEL
05 69 099
OPEL
13504280
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.12~12.17 | 1400 | A14NET | J305 | RN34001VRN34003V | PN0757PN0391 | RN34002RN34004 | PN0392 | |
| 05.09~12.17 | 1600 | F16D4 / LDE | JA68E9 | RN34001VRN34003V | PN0391PN0757 | RN34002DN1683RN34004 | PN0392FN0665 | |
| 02.16~ | 2000 | LNP / Z20D1 | 1PU68 | RN34003V | PN0757 | RN34004 | PN0392 |
| 01.13~01.17 | 1400 | A14NET | J308 | RN34003VRN34001V | PN0391PN0757 | RN34002RN34004 | PN0392 | |
| 11.12~01.17 | 2000 | LNP / Z20D1 | 1P#35 RHD SG | RN34001VRN34003V | PN34002PN0391 | RN34002RN34004 | PN0392 |
| 03.11~12.17 | 1400 | A14NET / LUJ | YA75 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 01.12~01.18 | 1600 | LVL | RPC75 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 03.11~01.18 | 1800 | F18D4 (2H0) | YA75 RHD | RN34003V | PN0757 | RN34004 | PN0392 | |
| 03.11~01.18 | 1800 | F18D4 (2H0) | YF75 EU LHD | RN34003V | PN0757 | RN34004 | PN0392 | |
| 03.11~12.17 | 2000 | LNP / Z20D1 | YA75 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 01.12~12.17 | 2400 | LAF | 1PK75 | RN34003V | PN0757 | RN34004 | PN0392 |
| 08.10~01.16 | 1800 | F18D4 (2H0) | KLAJA69 | RN34001VRN34003V | PN0757PN0391 | DN1683RN34002RN34004 | FN0665PN0392 | |
| 08.10~01.16 | 2000 | LNP / Z20D1 | KLAJF69 | RN34003V | PN0757 | RN34004 | PN0392 |
| 12.09~01.16 | 1400 | A14NET | J | RN34003V | PN0757 | RN34004RN34002 | PN0392 | |
| 09.09~10.15 | 1600 | A16LET | P10 | RN34003V | PN0757 | RN34004 | PN0392 | |
| 12.09~01.16 | 1600 | A16XHT | J | RN34003V | PN0757 | RN34002RN34004 | PN0392 | |
| 01.09~10.15 | 1700 | A17DT# | J | RN34001VRN34003V | PN34002PN0391 | RN34002RN34004 | PN0392 | |
| 11.09~10.15 | 2000 | A20DTH | J | RN34003V | PN0391 | RN34004 | PN0392 | |
| 10.12~10.15 | 2000 | A20DTR | J | RN34003V | PN0391 | RN34004 | PN0392 | |
| 09.09~10.15 | 2000 | Z20DTJ | E68 5DR HB | RN34003V | PN0757 | RN34004 | PN0392 |
| 03.13~01.20 | 1600 | A16XHT | W13 | RN1679V | PN34002 | RN34004 | PN0392 | |
| 01.13~06.19 | 1600 | B16SHL | W13 | RN1679V | PN34002 | RN34004 | PN0392 |
