NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2291V

Product
Application

ROTOR DISC » RN2291V

Specification

Type

Vented

Outter Ø

320

Num. of holes

5

Hole Ø:

13.1

Disc Thickness (Max)

28

Disc Thickness (Min)

26

Height

47

Centering Diameter

64

Pitch Circle Ø

114.3

Drum Ø:

155

Front/Rear

Front

Structure Material

G3000

Cross Reference

GREAT WALL

3501011XKY00A

HAVAL

3501011XKY00A

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HAVAL » F7

12.18~07.24	1500	GW4B15A	CC6475UM	RN2291V	PN8802	RN2292	PN6016
12.18~07.24	2000	GW4C20		RN2291V	PN8802	RN2292	PN6016
