ROTOR DISC » RN2289V

Specification

Type
Vented
Outter Ø
343
Num. of holes
6
Hole Ø:
16
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
58.5
Centering Diameter
78.6
Pitch Circle Ø
139.6
Drum Ø:
183.8
Front/Rear
Front
Structure Material
G3000

Cross Reference

GM
13514522
GM
13542112
GM
13553983
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.20~ 6200 L87 TK10_06 RN2289V PN52006W RN2290V PN5013W
08.18~ 6200 L87 GMT1CC (K1500) RN2289V PN52006W RN2290V PN5013W
07.20~ 5300 L84 K10906 RN2289V PN52006W RN2290V PN5013W
05.20~ 3000 LM2 CK10706 RN2289V PN52006W RN2290V PN5013W
05.20~ 5300 L84 GMT1YC RN2289V PN52006W RN2290V PN5013W
05.20~ 6200 L87 GMT1YC RN2289V PN52006W RN2290V PN5013W
02.19~ 6200 L87 TK10543 RN2289V PN52006W RN2290V PN5013W
01.20~ 6200 L87 TK10743 RN2289V PN52006W RN2290V PN5013W
07.20~ 6200 L87 TK10706 RN2289V PN52006W RN2290V PN5013W

Exemption from liability: the catalog data is advisory and can be used for reference only
