ROTOR DISC » RN2255V
Specification
Type
Vented
Outter Ø
356
Num. of holes
5
Hole Ø:
15.3
Disc Thickness (Max)
34
Disc Thickness (Min)
31.5
Height
52.1
Centering Diameter
68
Pitch Circle Ø
112
Drum Ø:
149
Front/Rear
Front
Structure Material
G3000
Cross Reference
VAG
4G0 615 301 A
VAG
4G0 615 301 K
VAG
4G0 615 301 T
VAG
4H0 615 301 F
VAG
4H0 615 301 K
VAG
4H0 615 301 R
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.15~05.18 | 1800 | CYGA | SB SPORTBACK | RN2255VRN1741VRN1736V | PN0894PN33004WPN0477WPN0556PN0556W | RN2520VRN1734VRN33002 | PN0478W | |
| 11.11~03.15 | 3000 | CGQB | 4GA0VA | RN2255V | PN0556WPN0556 | RN1734V | PN0478W | |
| 07.10~05.12 | 3000 | CGWB | 4GA06Y | RN2255V | PN0556WPN0556 | RN1734V | PN0478PN0478W | |
| 05.14~05.18 | 3000 | CREC | 4GF02Y | RN2255V | PN0556WPN0556 | RN1734V | PN0478PN0478W | |
| 07.14~05.18 | 3000 | CRTF | 4GF | RN2255V | PN0477WPN0556WPN0894PN33004WPN0556 | RN1734VRN33002 | PN0478W | |
| 11.15~05.18 | 3000 | CZVE | 4GF | RN1741VRN1736VRN2255V | PN0894PN33004WPN0477WPN0556PN0556W | RN2520VRN1734VRN33002 | PN0478W |
| 07.12~06.16 | 2500 | CPAA | SDN | RN2255V | PN33009WPN0556PN0556WPN33004W | RN1734VRN2520V | PN0719WPN0478W | |
| 07.10~12.13 | 3000 | CDTA | 4H80DA | RN2255V | PN0556PN0556W | RN1734V | PN0478W | |
| 07.10~04.14 | 3000 | CGWA | 4H80VA | RN2255V | PN0556WPN0556 | RN1734V | PN0478W | |
| 11.11~01.18 | 3000 | CGWD | SDN | RN2255V | PN0556PN33009WPN0556W | RN1734VRN2520V | PN0478W | |
| 05.11~09.13 | 3000 | CLAB | SDN | RN2255V | PN0556PN33009WPN0556W | RN1734VRN2520V | PN0478W | |
| 06.10~01.18 | 3000 | CMDA | SDN | RN2255V | PN0556WPN33004WPN33009WPN0556 | RN1734VRN2520V | PN0478WPN0719W | |
| 09.13~01.18 | 3000 | CREA | 4HL01A | RN2255V | PN0556WPN0556 | RN1734V | PN0478W |
