ROTOR DISC » RN2232V
Specification
Type
Vented
Outter Ø
280
Num. of holes
5
Hole Ø:
12.6
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
44.8
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
143.5
Front/Rear
Front
Structure Material
G3000
Cross Reference
HYUNDAI
51712-G2100
KIA
51712-G2000
KIA
51712-G2100
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.16~01.19 | 88kW | C#51 LHD | RN2232V | PN0772 | RN1601 | PN0538 | ||
| 03.16~01.19 | EM09 88kW | C851 RHD | RN2232V | PN0772 | RN1601 | PN0538 | ||
| 01.19~ | EM10 100kW | C851 SG | RN2232V | PN0772 | RN1601 | PN0538 | ||
| 03.16~01.19 | 1600 | G4LE | C75L US | RN2232V | PN0772 | RN2233 | PN0538 | |
| 03.16~01.19 | 1600 | G4LE | C851 | RN2232V | PN0772 | RN2233 | PN0538 | |
| 01.19~ | 1600 | G4LE | C851 | RN2232V | PN0772 | RN2233 | PN0538 |
| 08.18~ | EM16 | DE | RN2232VRN1653V | PN0772PN0578 | RN2450 | PN0538 | ||
| 09.21~ | 1600 | G4LE | PDE22 RHD PLUS | RN2232V | PN0772 | RN2616 | PN0538 | |
| 03.16~01.19 | 1600 | G4LE | PG516 RHD | RN2232V | PN0772 | RN2233 | PN0538 | |
| 03.16~01.19 | 1600 | G4LE | PG516 RHD SG | RN2232V | PN0772 | RN2233 | PN0538 | |
| 03.16~ | 1600 | G4LE | PG516 US | RN2232V | PN0772 | RN2233 | PN0538 | |
| 01.19~11.21 | 1600 | G4LE | PG519 RHD | RN2232V | PN0772 | RN2616 | PN0538 |
