ROTOR DISC » RN2225V

Specification

Type
Vented
Outter Ø
339
Num. of holes
5
Hole Ø:
16.5
Disc Thickness (Max)
23
Disc Thickness (Min)
21.5
Height
48.1
Centering Diameter
67.4
Pitch Circle Ø
120
Drum Ø:
201
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GM
15267108
GM
20808622
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.08~09.13 3000 LFW 6D_69 RN2224V PN51008 RN2225V PN51007

Exemption from liability: the catalog data is advisory and can be used for reference only
