NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2217V

Product
Application

ROTOR DISC » RN2217V

Specification

Type

Vented

Outter Ø

315

Num. of holes

5

Disc Thickness (Max)

23

Disc Thickness (Min)

21

Height

48

Centering Diameter

70.8

Pitch Circle Ø

115

Structure Material

G3000

Drum Ø:

201

Hole Ø:

14.3

Front/Rear

Rear

Cross Reference

CADILLAC (GM)

13581427

CADILLAC (GM)

13590083

GM

23118092

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CADILLAC (GM) » ATS

02.13~12.18	2000	LTG	6AC69	RN2216V	PN0150S	RN2217V	PN0718	FN0784
02.13~12.18	2500	LCV	6AB69	RN2216V	PN0150S	RN2217V	PN0718	FN0784
02.13~12.18	3600	LFX	6AB69	RN2216V	PN0150S	RN2217V	PN0718	FN0784
