ROTOR DISC » RN2211V

Specification

Type
Vented
Outter Ø
325
Num. of holes
6
Disc Thickness (Max)
29
Disc Thickness (Min)
27.4
Height
54.5
Centering Diameter
75.6
Pitch Circle Ø
132
Drum Ø:
175
Front/Rear
Front
Structure Material
G3000

Cross Reference

GM
10390111
GM
22955495
GM
25853001
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.08~03.17 3600 LLT RN2211V PN0517 RN2212V PN4802
04.07~08.08 3600 LY7 RN2211V PN0517 RN2212V PN4802
10.08~07.17 3600 LLT CR14526 RN2211V PN0517 RN2212V PN4802 FN0788
10.08~07.17 3600 LLT CV14526 RN2211V PN0517 RN2212V PN4802 FN0788
08.08~03.17 3600 LLT TV14526 RN2211V PN0517 RN2212V PN4802 FN0788

Exemption from liability: the catalog data is advisory and can be used for reference only
