DRUM BRAKE » DN1109
Specification
Outter Ø
239.7
Num. of holes
4
Centering Diameter
60
Pitch Circle Ø
114.3
Structure Material
G3000
Hole Ø
13.1
Height
59.6
Drum Ø
203
Cross Reference
SUZUKI
4309177J00000
TOYOTA
42431-BZ010
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.15~01.23 | 1300 | 1NR-VE | F653LM | RN2184V | PN1832 | DN1109 | FN2367 | |
| 07.15~01.23 | 1300 | 1NR-VE | F653RM | RN2184V | PN1832 | DN1109 | FN2367 | |
| 01.03~11.11 | 1300 | K3-VE | F601RM | RN2025 | PN1832 | DN1109 | FN2367 | |
| 11.11~08.15 | 1300 | K3VE | F651LM | RN2025 | PN1832 | DN1109 | FN2367 | |
| 08.15~01.23 | 1500 | 2NR-VE | F654LM | RN2184V | PN1832 | DN1109 | FN2367 | |
| 07.15~01.22 | 1500 | 2NR-VE | F654RM | RN2184V | PN1832 | DN1109 | FN2367 | |
| 10.06~11.11 | 1500 | 3SZ-VE | F602LM | RN2025 | PN1832 | DN1109 | FN2367 | |
| 11.11~08.15 | 1500 | 3SZ-VE | F652LM | RN2025 | PN1832 | DN1109 | FN2367 |
