DRUM BRAKE » DN1714

Specification

Outter Ø
246.5
Num. of holes
4
Hole Ø
12.4
Centering Diameter
64.1
Height
56
Pitch Circle Ø
100
Drum Ø
203
Structure Material
G3000

Cross Reference

MG
10135569
SAIC
30011032
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.11~ 1300 13S4F RN2515V DN1714
08.17~ 1500 15S4C RN2515V PN0785 DN1714 FN0602
03.11~ 1500 15S4U RN2515V PN0785 DN1714 FN0602

Exemption from liability: the catalog data is advisory and can be used for reference only
