DRUM BRAKE » DN1703

Specification

Outter Ø
219
Num. of holes
4
Hole Ø
13.2
Centering Diameter
59
Height
53
Pitch Circle Ø
98
Drum Ø
185
Structure Material
G3000

Cross Reference

FIAT
46448407
FIAT
5923606
FIAT
98601861
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.94~01.98 1100 176 B2.000 PN0287W DN1703 FN0507
03.98~02.00 900 1170 A1.046 221SE PN0287W DN1703 FN0507
03.98~02.00 900 1170 A1.046 222SE PN0287W DN1703 FN0507
03.98~08.00 1100 176 B2.000 (SPI) 187 RN1385 PN0287W DN1703 FN0507
09.00~01.10 1100 187A1.000 (MPI) 187 RN1385 PN0287W DN1703 FN0507

Exemption from liability: the catalog data is advisory and can be used for reference only
