DRUM BRAKE » DN1678

DN1678

Specification

Outter Ø
242
Num. of holes
4
Hole Ø
M12x1.5
Centering Diameter
39.9-50.2
Height
81
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

DAEWOO
96081274
DAEWOO
96193771
DAEWOO
96193876
GM
96193771
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHEVROLET (GM)   »   Lanos

04.05~06.09 1500 A15SMS TF69Y08 SDN ZAZ T PN0390 DN1678DN1841 FN11622

DAEWOO   »   Lanos

07.97~06.02 1300 A13SM KLAT PN0021 DN1678DN1841 FN11622
07.97~12.10 1400 A14SMS KLAT PN0234PN0390PN0374 DN1678DN1841 FN11622
08.97~06.99 1500 A15SMS KLAT PN0390 DN1678DN1841 FN11622
04.05~06.09 1500 LX6 T100 PN0390 DN1841DN1678 FN11622
04.97~06.99 1500 Y15L KLAT PN0021 DN1841DN1678 FN11622
08.97~06.02 1500 YA15SM KLAT PN0374PN0234 DN1841DN1678 FN11622
07.97~12.10 1600 A16DMS KLAT RN1017V PN0374PN0031 DN1841DN1678 FN11622
