DRUM BRAKE » DN1669

Specification

Outter Ø
244
Num. of holes
4
Centering Diameter
57
Height
58.2
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Hole Ø
12.7

Cross Reference

CHEVROLET
9064171
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.14~ 1500 L2B RN2202V PN0742 DN1669 FN0790
03.18~ 1500 L2B RN2202V PN0742 DN1669 FN0790

Exemption from liability: the catalog data is advisory and can be used for reference only
