DRUM BRAKE » DN1663

Specification

Outter Ø
265
Num. of holes
4
Centering Diameter
57
Height
69
Pitch Circle Ø
100
Drum Ø
230
Structure Material
G3000
Hole Ø
14.5

Cross Reference

CHEVROLET
93602828
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.12~12.18 1400 LQ5 1CH80 RN2150V PN0361 DN1663 FN0599
01.12~12.18 1800 LJ1 1CG80 RN2150V PN0361 DN1663 FN0599

Exemption from liability: the catalog data is advisory and can be used for reference only
