DRUM BRAKE » DN1661

Specification

Outter Ø
252
Num. of holes
5
Hole Ø
14
Centering Diameter
73.5
Height
68.1
Pitch Circle Ø
114.3
Drum Ø
220
Structure Material
G3000

Cross Reference

BENDIX
PDR0634
CHRYSLER
04601798
CHRYSLER
04616236
CHRYSLER
4601798
CHRYSLER
4616236
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.94~08.97 3500 EGE ACH41 PN0110 DN1661 PN0313
10.94~08.97 3500 EGE ACP41 PN0110 DN1661 PN0313
01.95~12.97 3300 EGD PN0110 DN1661 PN0313
01.95~12.97 3500 EGE PN0110 DN1661 PN0313

Exemption from liability: the catalog data is advisory and can be used for reference only
