DRUM BRAKE » DN1609
Specification
Outter Ø
234
Num. of holes
4
Hole Ø
M12x1.5
Centering Diameter
49.2-52.2
Height
76
Pitch Circle Ø
100
Drum Ø
203.2
Structure Material
G3000
Notes
w/o Wheel Bearing
Cross Reference
RENAULT
43 20 042 55R
RENAULT
43 20 064 68R
RENAULT
43 20 207 17R
RENAULT
43 20 225 46R
RENAULT
43 20 232 59R
RENAULT
43 20 247 63R
RENAULT
43 20 262 94R
RENAULT
43 20 266 17R
RENAULT
43 20 295 21R
RENAULT
60 01 547 703
RENAULT
77 00 428 821
RENAULT
77 00 818 346
RENAULT
77 00 827 866
RENAULT
77 00 839 322
RENAULT
82 00 243 735
RENAULT
82 00 290 352
RENAULT
82 00 672 836
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.98~09.12 | 1000 | D4D | BB# 5DR | RN1002V | PN0284W | DN1609 | FN0602FN0556FN0619 | |
| 09.98~06.01 | 1200 | D7F 7# | BB 5DR HB | RN1037V | PN0284W | DN1609H | FN0619 | |
| 06.01~09.12 | 1200 | D7F 726 | BB2D | RN1037V | PN0284W | DN1609H | FN0619FN0602 | |
| 09.98~06.01 | 1200 | D7F720 | BB0A 5DR HB | RN1000RN1037VRN1002V | PN0284W | DN1607DN1609H | FN0619FN0778FN0602 | |
| 06.01~09.12 | 1500 | K9K 704 | BB07 5DR HB LHD | RN1000RN1037V | PN0284W | DN1609 | FN0602FN0556FN0619 |
| 08.04~06.15 | 1400 | K7J710 | LS0A | RN1191RN1000RN1037VRN1571V | PN0284W | DN1607DN1609 | FN0556FN0619 | |
| 01.05~12.07 | 1400 | K7J710 | LS0G | RN1037VRN1571VRN1191RN1000 | PN0284W | DN1607DN1609 | FN0619FN0602FN0556 |
| 01.08~08.14 | 1500 | K9K790 | LS0Y | RN1571VRN1191RN1037VRN1000 | PN0284W | DN1627HDN1595HDN1609H | FN0556FN0619FN0602 |
| 01.08~01.13 | 1500 | K9K 740 | LU3M | RN1002V | PN0284W | DN1609H | FN0602 | |
| 01.08~01.13 | 1600 | K4M 670 | LU0A | RN1037V | PN0284W | DN1609H | FN0602 |
| 03.93~06.07 | 3DR HB / LCV | RN1037VRN1191RN1000 | PN0284WPN0240 | DN1609 | FN0602FN0521 | |||
| 07.00~06.07 | 1200 | D4F 7# | 3DR HB / LCV | RN1191RN1037VRN1000 | PN0284W | DN1609 | FN0602FN0521 | |
| 09.98~08.04 | 1200 | D7F | C06_ | RN1000 | PN0249W | DN1609 | FN0602 |
| 03.07~09.14 | 1200 | D4F 7# | 3DR HB | RN1191RN1037V | PN0284W | DN1609H | FN0778 | |
| 03.07~02.12 | 1200 | D4F 722 | CN0A 3DR | RN1037V | PN0284W | DN1609H | ||
| 03.07~09.14 | 1200 | D7F 800 | 3DR HB | RN1191RN1037V | PN0284W | DN1609H | FN0778 | |
| 03.07~09.14 | 1500 | K9K 7# | 3DR HB | RN1191RN1037V | PN0284W | DN1609H | FN0778 | |
| 10.10~09.14 | 1500 | K9K820 | 3DR HB | RN1191RN1037V | PN0284W | DN1609H | FN0778 |
