DRUM BRAKE » DN1544

DN1544

Specification

Outter Ø
290
Num. of holes
4
Hole Ø
M12x1.5
Centering Diameter
39.8-50.2
Height
84.3
Pitch Circle Ø
100
Drum Ø
230
Structure Material
G3000
Notes
w/o Wheel Bearings

Cross Reference

VOLKSWAGEN
357 501 615
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

VOLKSWAGEN   »   Passat

03.91~03.97 1900 AAZ 31____ DN1544 FN0537
