DRUM BRAKE » DN1525

DN1525

Specification

Outter Ø
270
Num. of holes
5
Hole Ø
14.6
Centering Diameter
75.1
Height
58.7
Pitch Circle Ø
120
Drum Ø
228.5
Structure Material
G3000

Cross Reference

BMW
34 21 1 159 486
BMW
34 21 6 752 366
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

BMW   »   316i

09.90~09.93 1600 M40B16 E36 (4) PN0010 RN1300DN1525 PN0014FN0547 FN0544
09.93~10.99 1600 M43B16 E36 (4) PN0010 DN1525RN1300 FN0547PN0014 FN0544

BMW   »   318i

09.88~10.99 1800 M40B18E E36 (4) RN1014V PN0010 RN1300DN1525 PN0014FN0547 FN0544
09.93~10.99 1800 M43B18 E36 (3) PN0010 RN1300DN1525 PN0014FN0547 FN0544
