DRUM BRAKE » DN1479

Specification

Outter Ø
253
Num. of holes
5
Hole Ø
14.2
Centering Diameter
74.9
Height
162
Pitch Circle Ø
145
Drum Ø
220
Structure Material
G3000
Notes
w/o Bearing

Cross Reference

HYUNDAI / KIA
0K60B26251
KIA
0K60B26251A
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.06~01.17 2500 D4CB A2 1 TON - E/LONG RN2113V PN0600 DN1479 FN0814
11.06~ 2500 D4CB A2 K7#P VTN RN2113V PN0600 DN1479 FN0814
10.01~06.04 2500 D4BH (4D56) FR5SZ85 PN0433 DN1479 FN3350
01.03~09.07 2500 D4BH (4D56) SD RN1613V PN0433 DN1479 FN3350
12.01~06.04 2500 D4BH (4D56) SD71 PN5211 DN1479 FN3350
12.01~06.04 2500 D4BH (4D56) SD75 PN5211 DN1479 FN3350
12.01~06.04 2500 D4BH (4D56) SD85 PN5211 DN1479 FN3350
03.08~10.16 2500 D4CB A2 SJY76 RN2113V PN0600 DN1479 FN0814
01.04~11.06 2700 J2 SE0 RN1613V PN0433 DN1479 FN0814
01.04~11.06 2700 J2 SE9 RN1613V PN0433 DN1479 FN0814
03.14~12.16 2700 J2 SGX7 RN1613V PN0433 DN1479 FN0814
01.20~ 2700 J2 SGY7 DBL LHD RN1613V PN0433 DN1479 FN0814
01.20~ 2700 J2 SJZ7 SPR LHD RN1613V PN0433 DN1479 FN0814
03.08~ 2500 D4CB A2 SJX76 RN2276V PN0600 DN1479 FN0814

Exemption from liability: the catalog data is advisory and can be used for reference only
