DRUM BRAKE » DN1462

Specification

Outter Ø
272
Num. of holes
4
Hole Ø
12.7
Centering Diameter
90
Height
53.4
Pitch Circle Ø
114.3
Drum Ø
228.6
Structure Material
G3000

Cross Reference

BENDIX
PDR0607
HYUNDAI
58411-33001
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.88~04.93 1800 G4CM Y2 PN2176 DN1454DN1462
06.88~04.93 2000 G4CP Y2 PN2245 DN1454DN1462 FN11241PN0959

Exemption from liability: the catalog data is advisory and can be used for reference only
