DRUM BRAKE » DN1342

Specification

Outter Ø
240
Num. of holes
4
Hole Ø
12.6
Centering Diameter
69
Height
57.5
Pitch Circle Ø
114.3
Drum Ø
203
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
A 454 423 01 01
MITSUBISHI
4615A012
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.04~09.09 1100 134910 NZ32A EU RHD RN1212V PN3090 DN1342 FN6737
10.08~12.12 1300 4A90 Z33A RN1212V PN3090 DN1342 PN3593FN6737
08.04~09.08 1500 OM639 Z39A RN1212V PN3090 DN1342 PN3593FN6737

Exemption from liability: the catalog data is advisory and can be used for reference only
