DRUM BRAKE » DN1337

DN1337

Specification

Outter Ø
297
Num. of holes
5
Hole Ø
12.3
Centering Diameter
75.1
Height
70.4
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

MITSUBISHI
MB193595
MITSUBISHI
MR128127
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Delica Space Gear

03.94~04.99 2000 4G63 PA3V PN3369 DN1337 FN6715
06.94~03.01 2000 4G63 PA3W RN1121V PN3369PN3233 DN1337 FN6715
03.86~06.99 2500 4D56-T PD5W RN2589V PN3172 DN1337 FN6664

MITSUBISHI   »   Delica Star Wagon

04.86~10.98 2500 4D56-T P_5W RN2589VRN1335V PN3172 DN1337DN1339 FN6686FN6664

MITSUBISHI   »   L300

06.94~05.03 1600 4G92 P16V RN2589V PN3172 DN1337 FN6664
09.86~12.13 2000 4G63 P03W RN2589V PN3172 DN1337 FN6664
09.86~05.07 2000 4G63 P13W RN2589V PN3172 DN1337 FN6664
04.23~ 2200 4N14 L06A RN1809V DN1337 FN6664
11.86~01.95 2500 4D56 L039P RN1335VRN1809V PN3084PN3172 DN1337 FN6664
11.86~10.08 2500 4D56 P15V RN2589V PN3172 DN1337 FN6664
06.08~01.14 2500 4D56 P15V LONG RHD RN2589V PN3172 DN1337 FN6664
01.87~05.04 2500 4D56 P15W RN2589V PN3172 DN1337 FN6664

MITSUBISHI   »   L400

05.95~03.01 2000 4G63 PA3V PN3369 DN1337 FN6715FN6718
