DRUM BRAKE » DN1317

DN1317

Specification

Outter Ø
265
Num. of holes
4
Centering Diameter
68
Height
66.3
Pitch Circle Ø
114.3
Drum Ø
229
Structure Material
G3000
Hole Ø
12.8

Cross Reference

MITSUBISHI
MQ704795
NISSAN
43206-3LG0A
NISSAN
43206-JX00A
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Delica D:3

10.11~ 1600 HR16DE BM20 RN1619V PN2012 DN1317 FN0645
10.11~ 1600 HR16DE BVM20 RN1619V PN2012 DN1317 FN0645

NISSAN   »   NV200 Van

02.10~ 1500 K9K M20 RN1619V PN2012 DN1317 FN0645

NISSAN   »   NV200 Vanette

05.09~ 1600 HR16DE AM20Z RN1619V PN2012 DN1317 FN0645
05.09~ 1600 HR16DE VM20 JPN RN1619V PN2012 DN1317 FN0645
