DRUM BRAKE » DN1266

Specification

Outter Ø
296
Num. of holes
5
Hole Ø
14.6
Centering Diameter
61
Height
71.7
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

TOYOTA
42431-43021
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.08~01.18 2000 1TR-FPE TSS10H RN1301V PN1246 DN1266 FN2363
10.02~08.08 2000 1G-FE GBS12 RN1301V PN1246 DN1266 FN2363
08.01~08.07 2000 1G-FE GXS12 RN1301V PN1246 DN1266 FN2363
12.95~10.02 2000 1G-GPE GXS10 RN1301V PN1246 DN1265DN1266 FN2333FN2252FN2363
09.07~01.18 2000 1TR-FE TSS13Y RN1301V PN1246 DN1266 FN2363FN2232
08.08~01.18 2000 1TR-FPE TSS10 RN1301V PN1246 DN1266 FN2363
08.08~01.18 2000 1TR-FPE TSS11 RN1301V PN1246 DN1266 FN2363
08.08~01.18 2000 1TR-FPE TSS11Y RN1301V PN1246 DN1266 FN2363
12.95~08.08 2000 3Y-PE YXS10 RN1301V PN1246 DN1266DN1265 FN2252FN2363FN2333
10.01~06.07 2000 3Y-PE YXS10H RN1301V PN1246 DN1266 FN2363
12.95~08.08 2000 3Y-PE YXS11 RN1301V PN1246 DN1266DN1265 FN2252FN2363FN2333

Exemption from liability: the catalog data is advisory and can be used for reference only
