DRUM BRAKE » DN1257

Specification

Outter Ø
235
Num. of holes
5
Hole Ø
14.5
Centering Diameter
54
Height
66.5
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

TOYOTA
42431-32010
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.85~07.86 2000 2C-TL CV11 PN1077 DN1257 FN2285

Exemption from liability: the catalog data is advisory and can be used for reference only
