DRUM BRAKE » DN1255

Specification

Outter Ø
298
Num. of holes
4
Hole Ø
14.5
Centering Diameter
60
Height
73.4
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

TOYOTA
42431-28020
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.93~10.96 2200 3C-T CR22G RN1533V PN1404PN1328 DN1243DN1255 FN2252FN2232
01.92~10.96 2000 3Y YR39RV RN1533V PN1328 DN1255 FN2252
01.99~01.05 2400 2L LF50 RN1533V PN1404 DN1255
01.97~12.04 1800 KF80 DN1256DN1255
01.97~12.04 2400 LF80 DN1255DN1243DN1256

Exemption from liability: the catalog data is advisory and can be used for reference only
