DRUM BRAKE » DN1231

Specification

Outter Ø
240
Num. of holes
4
Hole Ø
13.3
Centering Diameter
55
Height
55.3
Pitch Circle Ø
88
Drum Ø
199

Cross Reference

MAZDA
DA7R-26-251
TOYOTA
42403-WB001
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.14~ 1500 P5 AEDMM1 EU LHD RN2495V PN5816 DN1231 FN0630
10.15~ 1500 RN2495V PN5816 DN1231 FN0630
06.15~08.17 1500 P5 DB7P RN2495V PN5816 DN1231 FN0630
06.15~08.17 1500 P5 DD1B RN2495V PN5816 DN1231 FN0630

Exemption from liability: the catalog data is advisory and can be used for reference only
