DRUM BRAKE » DN1215

Specification

Outter Ø
304
Num. of holes
5
Hole Ø
14.5
Centering Diameter
67
Height
71.9
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

TOYOTA
42431-04010
TOYOTA
42431-35080
TOYOTA
42431-35120
TOYOTA
42431-35150
TOYOTA
42431-35151
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.97~08.05 2000 1RZ-E RZN142L RN1026V PN1166 DN1209DN1215 FN2330FN2252
08.97~03.06 2000 1RZ-E RZN147 RN1026V PN1227 DN1209DN1215 FN2252FN2330
08.97~08.05 2000 1RZ-E RZN147L RN1026V PN1166 DN1209DN1215 FN2252FN2330
08.99~08.03 2000 1RZ-E RZN152H RN1026V PN1227 DN1215 FN2252
08.88~08.97 2400 22R RN80 RN1026V PN1166 DN1209DN1107DN1215 FN2330FN2260
08.85~08.05 2400 2L LN145R RN1475VRN1026V PN1166PN1830 DN1209DN1215 FN2330FN2252
08.83~03.89 2400 2L LN56L PN1071 DN1215 FN2252
08.01~08.05 2500 2KD-FTV KDN145 RN1475V PN1830PN1166 DN1215 FN2252
08.97~02.05 2700 3RZ-F RZN149R RN1026V PN1166 DN1215DN1209 FN2330FN2252
08.97~11.05 2700 3RZ-FE RZN144L RN1026V PN1166 DN1215 FN2252
08.97~03.06 3000 5L-E LN147 RN1026V PN1227 DN1215 FN2252
01.95~01.04 2400 2RZ-FE RZN140 RN1628V PN1246 DN1215 FN2252
09.00~09.04 2400 2RZ-FE RZN150 RN1628V PN1246 DN1215 FN2252
01.95~01.04 3400 5VZ-FE VZN150 RN1830V DN1215

Exemption from liability: the catalog data is advisory and can be used for reference only
