DRUM BRAKE » DN1211
Specification
Outter Ø
278
Num. of holes
5
Centering Diameter
62
Height
64.3
Pitch Circle Ø
114.3
Drum Ø
228
Structure Material
G3000
Hole Ø
14.7
Cross Reference
TOYOTA
42431-28100
TOYOTA
42431-42010
TOYOTA
42431-42011
TOYOTA
42431-42050
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.04~05.11 | 1800 | 1ZZ-FE | ZNM10G | RN1009V | PN1479 | DN1211 | FN2371 | |
| 09.09~01.18 | 1800 | 2ZR-FAE | ZGM10G | RN1009V | PN1479 | DN1211 | FN2371 |
| 01.01~01.07 | 2000 | 1AZ-FSE | AZR60G | RN1009V | PN1470 | DN1211 | FN2371 | |
| 01.01~01.07 | 2000 | 1AZ-FSE | AZR65 | RN1009V | PN1470 | DN1211 | FN2371 | |
| 06.07~04.10 | 2000 | 3ZR-FAE | ZRR70 | RN1434V | PN1524 | DN1211RN1229 | PN1449FN2371 | FN0567 |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR80 | RN1434V | PN1524 | RN1229DN1211 | PN1804FN2371 | FN0567 |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR80 | RN1434V | PN1524 | DN1211 | FN2371 | |
| 01.14~12.21 | 2000 | 3ZR-FAE | ZRR85 | RN1434V | PN1524 | DN1211 | FN2371PN1804 | FN0567 |
| 06.00~11.05 | 1800 | 1ZZ-FE | ZCA25L | RN1143V | PN1447 | RN1207DN1211 | PN1424FN2333 | FN0567 |
| 05.00~11.05 | 1800 | 1ZZ-FE | ZCA25W | RN1143V | PN1447 | DN1211 | FN2404 | |
| 01.00~12.04 | 1800 | 1ZZ-FE | ZCA26L | RN1143V | PN1447 | DN1211RN1207 | FN2333PN1424FN2404 | FN0567 |
| 06.00~11.05 | 1800 | 1ZZ-FE | ZCA26W | RN1143V | PN1447 | DN1211 | FN2333FN2404 | |
| 05.00~11.05 | 2000 | 1AZ-FE | ACA20R | RN1143V | PN1447 | DN1211RN1207 | FN2333PN1424 | FN0567 |
| 05.00~11.05 | 2000 | 1AZ-FE | ACA20W | RN1143V | PN1447 | DN1211RN1207 | FN2333PN1424 | FN0567 |
| 08.00~11.05 | 2000 | 1AZ-FE | ACA21L | RN1143V | PN1447 | RN1207DN1211 | PN1424FN2333 | FN0567 |
| 05.00~11.05 | 2000 | 1AZ-FE | ACA21R | RN1143V | PN1447 | DN1211RN1207 | PN1424FN2333FN2404 | FN0567 |
| 08.00~07.03 | 2000 | 1AZ-FE | ACA26L | RN1143V | PN1447 | DN1211 | FN2404FN2333 | |
| 05.00~11.05 | 2000 | 1AZ-FSE | ACA21W | RN1143V | PN1447 | DN1211RN1207 | FN2333PN1424 | FN0567 |
| 05.00~11.05 | 2000 | 1CD-FTV | CLA21L | RN1143V | PN1447 | DN1211RN1207 | FN2333PN1424 | FN0567 |
| 08.96~05.00 | 2000 | 3S-#E | SXA10W | RN1120V | PN1322 | DN1211RN1207 | FN2333PN1424 | FN0567 |
| 04.95~05.00 | 2000 | 3S-#E | SXA11 | RN1120V | PN1322 | RN1207DN1211 | PN1424FN2333 | |
| 01.94~05.00 | 2000 | 3S-FE | SXA10G | RN1120V | PN1322 | DN1211 | FN2333 | |
| 04.95~08.00 | 2000 | 3S-FE | SXA11L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 04.95~05.00 | 2000 | 3S-FE | SXA11R | RN1120V | PN1322 | DN1211 | FN2333 | |
| 09.97~05.00 | 2000 | 3S-FE | SXA15G | RN1120V | PN1322 | DN1211 | FN2333 | |
| 02.96~08.00 | 2000 | 3S-FE | SXA15L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 09.97~05.00 | 2000 | 3S-FE | SXA16G | RN1120V | PN1322 | DN1211 | FN2333 | |
| 02.96~08.00 | 2000 | 3S-FE | SXA16L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 01.93~01.00 | 2000 | 3SFE | SXA10L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 07.03~11.05 | 2400 | 2AZ-FE | ACA28L | RN1143V | PN1447 | DN1211RN1207 | FN2404PN1424 | FN0567 |
