DRUM BRAKE » DN1202H

DN1202H

Specification

Outter Ø
206
Num. of holes
4
Centering Diameter
40.32
Height
80.6
Pitch Circle Ø
100
Drum Ø
180
Structure Material
G3000

Cross Reference

TOYOTA
42043-19045
TOYOTA
42403-19085
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Corolla II

09.94~07.99 1300 4E-FE EL51 RN1097V PN1077 DN1227HDN1202H FN2321
09.94~07.99 1500 1N-T NL50 RN1097V PN1077 DN1202HDN1227H FN2321
09.94~10.99 1500 5E-FE EL53 RN1097V PN1077 DN1202HDN1227H FN2321

TOYOTA   »   Cynos

08.95~07.99 1300 4E-FE EL52 RN1097V PN1077 DN1227HDN1202H FN2321
08.96~03.99 1300 4E-FE EL52C RN1097V PN1077 DN1202H FN2321
08.95~07.99 1500 5E-FHE EL54 RN1115V PN1077 DN1227HDN1202H FN2321

TOYOTA   »   Paseo

09.96~03.99 1500 5E-FE EL54Convertible RN1097VRN1115V PN1077 DN1202H FN2321
08.95~07.99 1500 5E-FE EL54L RN1097VRN1115V PN1077 DN1202HDN1227H FN2321

TOYOTA   »   Tercel

09.94~07.99 1500 5E-FE EL53L RN1097V PN1077 DN1202HDN1227H FN2321
