ROTOR DISC » RN2143V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
22
Disc Thickness (Min)
20.5
Height
67
Centering Diameter
72.6
Pitch Circle Ø
115
Drum Ø:
184
Front/Rear
Rear
Structure Material
G3000

Cross Reference

CHRYSLER
04779 209AA
CHRYSLER
04779 209AB
CHRYSLER
04779 209AC
CHRYSLER
04779 209AC 64
CHRYSLER
04779 209AD
CHRYSLER
04779 209AE
CHRYSLER
04779 209AF
CHRYSLER
04779 209AG
CHRYSLER
4779209AE
CHRYSLER
68241 042AA
CHRYSLER
68241 042AB
CHRYSLER
68368 071AA
CHRYSLER
68368 072AA
OEM
4779209DC
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.05~06.09 3000 OM 642 RN2144V PN0423PN0421 RN2143V PN0422
08.04~10.10 3500 EGG RN2144V PN0423PN0421 RN2143V PN0422
01.06~12.10 3500 EGG LEZS48 RN2144V PN0421 RN2143V PN0422 FN0719
09.10~ 3600 ERB LX RN2144V PN0423PN0421 RN2143V PN0422 FN0719
01.05~12.08 5700 EZB LXCS48 RN2144V PN0421 RN2143V PN0422 FN0719
09.10~ 5700 EZH LXCP48 RN2144V PN0421 RN2143V PN0422 FN0719
02.02~06.07 6100 ESF HEMI RN2144V PN0423PN0421 RN2143V PN0422
01.17~ 3600 ERB LA RN2144V PN0421 RN2143V PN0422 FN0719
09.11~ 3600 ERB LD RN2144V PN0423PN0421 RN2143V PN0422 FN0719
01.04~12.08 5700 EZB LXDP48 RN2144V PN0421 RN2143V PN0422 FN0719
09.10~ 5700 EZH LDDP48 RN2144V PN0421 RN2143V PN0422 FN0719

Exemption from liability: the catalog data is advisory and can be used for reference only
