ROTOR DISC » RN2134V

Specification

Type
Vented
Outter Ø
315
Num. of holes
5
Disc Thickness (Max)
20
Disc Thickness (Min)
18.4
Height
44.5
Centering Diameter
85
Pitch Circle Ø
130
Drum Ø:
178
Structure Material
G3000
Front/Rear
Rear

Cross Reference

SSANGYONG
4840136100
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.17~ 2000 G20DTR Y400 RN2133V PN0446 RN2134V PN0898

Exemption from liability: the catalog data is advisory and can be used for reference only
