BRAKE SHOE » FN2267

FN2267

Specification

Radius
114
Width
50
Thickness
4
Pcs In Set
4

Cross Reference

AKEBONO
NR1024
BENDIX AUS
BS1450
DAIHATSU
04494-20110-000
DAIHATSU
04494-20130-000
DAIHATSU
04494-28020-000
DAIHATSU
04496-20110-000
DAIHATSU
04496-28020-000
KASHIYAMA
K-2267
TOYOTA
04494-20110
TOYOTA
04494-20120
TOYOTA
04494-20121
TOYOTA
04494-20130
TOYOTA
04494-28020
TOYOTA
04496-20110
TOYOTA
04496-20120
TOYOTA
04496-28020
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Corona

12.86~11.91 2000 2C CT141 PN1192PN1069FN2267 FN2268

TOYOTA   »   Lite/Townace

10.82~08.85 1800 1C CM20V RN1336V FN2267PN1328 DN1243 FN2232FN2220

TOYOTA   »   Lite/Townace Truck

10.82~09.86 1300 4K-J KM21 RN1336V PN1328FN2267 DN1243 FN2232FN2220
10.82~08.85 1800 1C CM20 RN1336V PN1328FN2267 DN1243 FN2220FN2269FN2232
10.82~09.86 1800 1C CM25 RN1336V FN2267PN1328 FN2269
10.82~09.86 2000 2C CM26 RN1336V FN2267PN1328 FN2269

TOYOTA   »   Liteace

10.82~05.85 1300 4K-J KM21 RN1336V PN1328FN2267 DN1243 FN2269FN2220FN2232

TOYOTA   »   Townace

10.82~08.88 1800 1C CR26V RN1336V FN2267PN1328 DN1243 FN2232FN2220
