ROTOR DISC » RN1469V

Specification

Type
Vented
Disc Thickness (Max)
26
Num. of holes
5
Height
44
Centering Diameter
68
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
296
Disc Thickness (Min)
23
Drum Ø:
146
Structure Material
G3000

Cross Reference

NISSAN
40206-1KC2A
NISSAN
40206-1KC3A
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.10~01.20 1600 MR16DDT F15E RN1469V PN2201 RN1302 PN2466 FN0621
07.10~01.20 1600 MR16DDT F15E RHD RN1469V PN2201 RN1302 PN2466 FN0621
02.15~ 1600 MR16DDT C13M RN1426VRN1469V PN2201 RN1302 PN2466 FN0621

Exemption from liability: the catalog data is advisory and can be used for reference only
