ROTOR DISC » RN1410V

RN1410V

Specification

Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
47.3
Centering Diameter
70
Front/Rear
Front
Pitch Circle Ø
120
Outter Ø
330
Drum Ø:
153.5
Disc Thickness (Min)
26
Hole Ø:
14.7
Structure Material
G3000
Notes

Cross Reference

HONDA
45251-STX-A00
HONDA
45251-STX-A01
HONDA
45251-STX-H01
HONDA
45251-TY3-A00
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ACURA   »   MDX

02.06~04.13 3700 J37A1 YD2 RN1410V PN28001 RN1411 PN28002 FN0690

ACURA   »   RLX

12.12~06.20 3500 J35Y4 KC2 RN1410V PN28001 PN0648

ACURA   »   ZDX

03.09~09.13 3700 J37A5 YB1 RN1410V PN28001 RN1411 PN28002 FN0690

HONDA   »   Legend

01.15~12.21 3500 JNB KC2 RN1410V PN28001 PN0648

HONDA   »   Pilot

04.08~04.15 3500 J35Z4 YF3 RN1410V PN28001 RN1411 PN28002 FN0690
04.08~12.11 3500 J35Z4 YF4 RN1410V PN28001 RN1411 PN28002 FN0690
12.11~01.16 3500 J35Z4 YF4 KY RN1410V PN28001 RN1411 PN28002 FN0690
05.08~12.11 3500 J35Z4 YF4 US RN1410V PN28001 RN1411 PN28002 FN0690
12.11~01.16 3500 J35Z4 YF4 US RN1410V PN28001 RN1411 PN28002 FN0690
