ROTOR DISC » RN1407
Specification
Type
Solid
Disc Thickness (Max)
9
Num. of holes
5
Height
57.2
Centering Diameter
70
Front/Rear
Rear
Outter Ø
304.8
Pitch Circle Ø
114.3
Drum Ø:
189
Disc Thickness (Min)
8
Structure Material
G3000
Cross Reference
HONDA
42510-TL0-G50
HONDA
42510-TL0-G51
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.08~08.10 | 2000 | R20A3 | CP1 RHD | RN1406VRN1413V | PN8865PN8465 | RN1409RN1407 | PN8807PN8864 | |
| 08.10~09.12 | 2000 | R20A3 | CP1 RHD | RN1406VRN1413V | PN8465PN8865 | RN1409RN1407 | PN8864PN8807 | |
| 01.08~03.13 | 2000 | R20A3 | EURO | RN1406VRN1408V | PN8865PN8863PN8465 | RN1409RN1407 | PN8864PN8807 | |
| 05.08~07.11 | 2200 | N22B1 | CU3 | RN1408V | PN8863 | RN1407 | PN8807 | FN0663 |
| 09.09~06.15 | 2200 | N22B1/2 | EURO | RN1204VRN1406V | PN8865PN8863 | RN1407 | PN8807 | FN0663 |
| 12.08~03.13 | 2400 | K24A | CU8 | RN1406VRN1413V | PN8865PN8465 | RN1407RN1409 | PN8864PN8807 | FN0663 |
| 01.08~08.10 | 2400 | K24Z | CP2 RHD | RN1406VRN1413V | PN8465PN8865 | RN1409RN1407 | PN8864PN8807 | |
| 05.08~03.13 | 2400 | K24Z | CU2 LHD | RN1406V | PN8865 | RN1407 | PN8807 | FN0663 |
| 05.08~03.13 | 2400 | K24Z | CU2 LHD CH | RN1406V | PN8865 | RN1407 | PN8807 | FN0663 |
| 05.08~03.13 | 2400 | K24Z | CU2 RHD | RN1406VRN1413V | PN8465PN8865 | RN1407RN1409 | PN8864PN8807 | FN0663 |
| 07.08~03.13 | 2400 | K24Z3 | EURO | RN1413VRN1406V | PN8465PN8865 | RN1407RN1409 | PN8864PN8397 |
