ROTOR DISC » RN1394V

Specification

Type
Vented
Disc Thickness (Max)
32
Num. of holes
5
Height
54.7
Centering Diameter
67
Front/Rear
Front
Pitch Circle Ø
112
Outter Ø
330
Disc Thickness (Min)
30
Drum Ø:
156
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
1644210412
MERCEDES-BENZ
1644211312
MERCEDES-BENZ
A 164 421 13 12
MERCEDES-BENZ
A1644210412
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.05~09.11 3000 OM 642.940 W164 RN1394V PN0500 RN1539 PN0507 FN0638
03.10~12.11 3000 M 272.945 W164 RN1394V PN0500 RN1539 PN0507 FN0638
10.05~12.11 3000 OM 642.940 W164 RN1394V PN0500 RN1539RN1538V PN0507 FN0638
02.05~12.11 3500 M 272.967 164.186 RN1394V PN0500 RN1539 PN0507 FN0638
01.07~01.10 3000 M 272.945 W251 RN1394V PN0500 RN1539RN1538V PN0507 FN0638
06.06~06.09 3000 OM 642.950 W251 RN1704VRN1394V PN0500 RN1538VRN1539 PN0507 FN0638
07.09~12.12 3000 OM 642.950 W251 RN1394VRN1704V PN0500 RN1539RN1538V PN0507 FN0638
01.06~07.10 3000 OM 642.950 W251 RN1394V PN0500 RN1539RN1538V PN0507 FN0638
05.09~12.14 3000 OM 642.870 W251 RN1704VRN1394V PN0500 RN1538V PN0507 FN0638
08.10~12.14 3000 OM 642.872 W251 RN1394VRN1704V PN0500 RN1539RN1538V PN0507 FN0638
09.05~12.17 3500 M 272.967 S251 RN1394V PN0500 RN1539 PN0507 FN0638
08.05~12.12 3500 M 272.967 W251 RN1394V PN0500 RN1539RN1538V PN0507 FN0638

Exemption from liability: the catalog data is advisory and can be used for reference only
