ROTOR DISC » RN1352
Specification
Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
36.8
Centering Diameter
62
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
270
Drum Ø:
155
Disc Thickness (Min)
8
Structure Material
G3000
Notes
TOYOTA AURIS _ZE15_, RE_15_.
Cross Reference
TOYOTA
42431-02170
TOYOTA
42431-02180
TOYOTA
42431-12280
TOYOTA
42431-YZZAE
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.07~10.12 | 1300 | 1NR-FE | NRE150 | RN1351V | PN1834 | RN1352 | PN1835 | |
| 10.12~05.15 | 1300 | 1NR-FE | NRE180 | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.06~10.12 | 1400 | 1ND-TV | NDE150L | RN1351V | PN1834 | RN1352 | PN1835 | |
| 10.12~11.18 | 1400 | 1ND-TV | NDE180L | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.12~11.18 | 1400 | 1ND-TV | NDE180R | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.06~12.08 | 1400 | 4ZZ-FE | ZZE150L | RN1238VRN1351V | PN1524PN1834 | RN1352RN1239 | PN1835PN1519 | |
| 05.15~ | 1600 | 1WW | WWE185 | RN21001V | PN21001 | RN1352 | PN1835 | |
| 09.09~10.12 | 1600 | 1ZR-FAE | ZRE151L | RN1351V | PN1524PN1834 | RN1352 | PN1835PN1519 | |
| 12.08~10.12 | 1600 | 1ZR-FAE | ZRE151R | RN1238VRN1351V | PN1524PN1834 | RN1239RN1352 | PN1835PN1519 | |
| 01.13~ | 1600 | 1ZR-FAE | ZRE181 | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.12~05.15 | 1600 | 1ZR-FAE | ZRE185 | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.12~ | 1600 | 1ZR-FAE | ZRE185L | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.12~ | 1600 | 1ZR-FAE | ZRE185R | RN21001V | PN21001 | RN1352 | PN1835 | |
| 10.06~08.12 | 1600 | 1ZR-FE | ZRE151L | RN1351VRN1238V | PN1524PN1834 | RN1239RN1352 | PN1519PN1835 | |
| 02.07~10.12 | 1600 | 1ZR-FE | ZRE151R | RN1351V | PN1834 | RN1352 | PN1835 | |
| 10.06~12.08 | 1800 | 2ZR-FE | ZRE152H | RN1238VRN1351V | PN1524PN1834 | RN1352RN1239 | PN1835PN1519 | |
| 06.10~10.12 | 1800 | 2ZR-FXE | ZWE150L | RN1241VRN1351V | PN1834PN1530 | RN1352 | PN1835PN1519 | |
| 06.13~11.18 | 1800 | 2ZR-FXE | ZWE186L | RN1241V | PN1530 | RN1352 | PN1835 | |
| 06.07~01.09 | 2000 | 1AD-FTV | ADE150 | RN1471V | PN1837 | RN1352 | PN1835 | |
| 10.12~05.15 | 2000 | 1AD-FTV | ADE186 | RN1471V | PN1837 | RN1352 | PN1835 | |
| 03.07~10.12 | 2200 | 2AD-FHV | ADE157 | RN1238VRN1351V | PN1834PN1524 | RN1239RN1352 | PN1835PN1519 |
| 02.09~01.14 | 1300 | 1NR-FE | NRE150R S. AFR | RN1351V | PN1834 | RN1352 | PN1835 | |
| 06.13~12.19 | 1300 | 1NR-FE | NRE180 | RN21001V | PN21001 | RN1352 | PN1835 | |
| 01.14~12.19 | 1300 | 1NR-FE | NRE180R | PN21001 | RN1352 | PN1835 | ||
| 11.06~04.13 | 1400 | 1ND-TV | NDE150L | RN1351V | PN1834 | RN1352 | PN1835 | |
| 02.08~06.13 | 1400 | 1ND-TV | NDE150R | RN1351V | PN1834 | RN1352 | PN1835 | |
| 06.13~12.19 | 1400 | 1ND-TV | NDE180 | RN21001V | PN21001 | RN1352 | PN1835 | |
| 11.06~12.08 | 1400 | 4ZZ-FE | ZZE150R | RN1351VRN1238V | PN1524PN1834 | RN1239RN1352 | PN1519PN1835 | |
| 11.06~04.13 | 1600 | 1ZR | ZRE151 | RN1238VRN1351V | PN1834PN1524 | RN1352RN1239 | PN1519PN1835 | |
| 11.06~11.19 | 1600 | 1ZR | ZRE151L | RN1238VRN1351V | PN1834PN1524 | RN1239RN1352 | PN1835PN1519 | |
| 06.13~01.19 | 1600 | 1ZR-FE | ZRE181L | RN1238VRN21001V | PN21001PN1524 | RN1352RN1239 | PN1519PN1835 | |
| 01.13~ | 1600 | 1ZR-FE | ZRE181R | RN21001V | PN21001 | RN1352 | PN1835 | |
| 03.07~02.09 | 1800 | 2ZR-FE | ZRE152R | RN1238VRN1351V | PN1524PN1834 | RN1352RN1239 | PN1835PN1519 | |
| 06.13~ | 1800 | 2ZR-FE | ZRE182L | RN21001V | PN21001 | RN1352 | PN1835 | |
| 03.15~ | 1800 | 2ZR-FE | ZRE182R | RN1238V | PN21001PN1524 | RN1239RN1352 | PN1519PN1835 | |
| 11.06~01.14 | 2000 | 1AD-FTV | ADE150L | RN1471V | PN1837 | RN1352 | PN1835 | |
| 07.07~01.14 | 2000 | 1AD-FTV | ADE150R | RN1471V | PN1837 | RN1352 | PN1835 | |
| 10.10~01.14 | 2000 | 3ZR-FE | ZRE153 | RN1351V | PN1834 | RN1352 | PN1835 |
