BRAKE SHOE » FN0552

Specification

Radius
89
Width
25
Pcs In Set
4
Thickness
6.5

Cross Reference

FMSI
S820-1553
VOLVO
271998
VOLVO
2719987
VOLVO
272288
VOLVO
274270
VOLVO
31262626
VOLVO
3516881
VOLVO
35168814
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.94~10.96 2000 B5204FS RN1055VRN1287V PN0020 RN1045 PN0007 FN0552
08.93~10.96 2300 B5234FT RN1287VRN1055V PN0020 RN1045 PN0007 FN0552
01.94~10.96 2400 B5252FS RN1287VRN1055V PN0020 RN1045 PN0007 FN0552
01.94~10.96 2400 B5254FS RN1287VRN1055V PN0020 RN1045 PN0007 FN0552
03.97~09.05 2000 B5204T3 RN1055V PN0020 RN1290 PN0007 FN0552
06.97~08.02 2000 B5204T4 RN1055V PN0020 RN1290 PN0007 FN0552
03.97~06.02 2300 B5234T3 873 RN1055V PN0020PN0188W RN1290 PN0007 FN0552
03.97~09.05 2400 B5254T RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2000 B5202 P80LS RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2000 B5204 P80LS RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2000 B5204T3 PN0188W PN0007 FN0552
11.96~09.00 2300 B5234T3 RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2400 B5244 P80LS RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2400 B5252FS P80LS RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2400 B5254 P80LS RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2400 GB 5252 S P80LS RN1055V PN0020 RN1290 PN0007 FN0552
11.96~09.00 2500 D5252T PN0188W RN1290 PN0007 FN0552
11.96~09.00 2000 B5202FS RN1113V PN0137PN0020PN0188W RN1290 PN0405PN0007 FN0552FN0566
11.96~09.00 2000 B5204T2 RN1113V PN0020 RN1290 PN0007 FN0552
10.97~09.00 2000 B5204T3 PN0020PN0188W PN0007 FN0552
11.96~09.99 2300 B5234T3 PN0188WPN0020 PN0007 FN0552
10.97~09.99 2300 B5234T3 PN0188WPN0020 PN0007PN0260 FN0552
11.96~09.99 2300 B5234T4 PN0020PN0188W PN0007PN0260 FN0552
11.96~09.99 2300 B5234T6 PN0020PN0188W PN0260PN0007 FN0552
11.96~09.99 2400 B524 PN0020 PN0007 FN0552
07.97~09.99 2400 B5244SG RN1167V PN0020 RN1290 PN0007 FN0552
11.96~09.99 2400 B525 PN0020 PN0007 FN0552
11.96~09.99 2400 B5252FS PN0020PN0188W PN0007 FN0552
11.96~02.00 2400 B5254FS LW55 RN1055V PN0020PN0188W RN1290 PN0007 FN0552
11.96~09.99 2400 B5254T PN0020PN0188W PN0007PN0260 FN0552
10.97~09.99 2400 B5254T PN0020 PN0260 FN0552
07.97~09.99 2400 GB 5252 S RN1167V PN0020 RN1290 PN0007 FN0552
11.96~10.01 2500 D5252T RN1055V PN0020 RN1290 PN0007 FN0552

Exemption from liability: the catalog data is advisory and can be used for reference only
