ROTOR DISC » RN1329V

Specification

Type
Vented
Disc Thickness (Max)
22
Num. of holes
6
Height
34
Centering Diameter
84
Front/Rear
Front
Outter Ø
258
Pitch Circle Ø
104

Cross Reference

MITSUBISHI
MB407031
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.86~01.97 1600 4G32 K11T RN1329V PN3172
01.86~03.01 2000 4G63 K12T RN1329V PN3172 FN6664
01.86~01.97 2000 4G63 K22T RN1329V PN3172
01.86~01.97 2000 4G63 K32T RN1329V PN3172 DN1339
01.86~01.97 2400 4G64 K05T RN1329V PN3172 DN1339 FN6664
01.86~01.97 2500 4D56 K14T RN1329V PN3172 FN6664
01.86~01.97 2500 4D56 K24T RN1329V PN3172 FN6664
01.86~01.97 2600 4G54 K13T RN1329V PN3172 DN1339 FN6664

Exemption from liability: the catalog data is advisory and can be used for reference only
