NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1281V

Product
Application

ROTOR DISC » RN1281V

Specification

Type

Vented

Disc Thickness (Max)

Num. of holes

Height

64.7

Centering Diameter

68.2

Pitch Circle Ø

112

Front/Rear

Front

Outter Ø

279.8

Cross Reference

BENDIX

561610B

VAG

701 615 301 D

VOLKSWAGEN

701615301A

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

VOLKSWAGEN » Multivan

09.90~12.95

2400

AAB

70B

RN1281V RN1053

PN0278 PN0160W

DN1543

FN0538

VOLKSWAGEN » Transporter

10.92~01.96	1900	ABL	T4	RN1295V RN1053 RN1389V RN1281V	PN0278 PN0224 PN0266 PN0340W PN0160W PN0278W	PN0035W FN0538
10.90~01.96	2500	AEN	T4	RN1053 RN1281V RN1389V	PN0160W PN0278 PN0278W PN0224 PN0266 PN0340W	FN0538 PN0035W PN0394
09.95~01.96	2500	AUF	T4	RN1281V RN1389V RN1053	PN0340W PN0160W PN0266 PN0108W PN0278W PN0278 PN0224	FN0538 PN0394 PN0035W
09.95~01.96	2500	AXL	T4	RN1281V RN1053 RN1389V	PN0160W PN0224 PN0266 PN0278 PN0340W PN0108W PN0278W	PN0035W FN0538 PN0394

VOLKSWAGEN » Transporter T4 (90)

09.90~01.96	1900	1X	T4	RN1389V RN1281V RN1053 RN1295V	PN0160W PN0224 PN0266 PN0340W PN0278 PN0278W		PN0035W FN0538
07.90~01.96	2000	AAC	T4	RN1389V RN1053 RN1281V RN1295V	PN0160W PN0278 PN0278W PN0224 PN0266 PN0340W		FN0538 PN0035W PN0394
07.90~01.96	2400	AAB	T4	RN1281V RN1389V RN1053	PN0266 PN0340W PN0160W PN0278 PN0278W PN0224		FN0538 PN0035W PN0394
09.90~12.93	2500	AAF	70C2D2	RN1053 RN1281V	PN0278 PN0160W PN0266	DN1543	FN0538
10.90~01.96	2500	ACU	T4	RN1389V RN1281V RN1053	PN0160W PN0278 PN0278W PN0224 PN0266 PN0340W		PN0035W FN0538 PN0394
09.95~01.96	2500	ACV	7D____	RN1281V RN1389V RN1053	PN0340W PN0266 PN0160W PN0278 PN0278W PN0108W PN0224		PN0035W FN0538 PN0394
01.96~06.03	2500	AET	T4	RN1281V RN1389V	PN0278W PN0224 PN0278 PN0160W PN0340W PN0108W		PN0035W FN0538 PN0394
08.96~06.03	2500	AEU	T4	RN1389V RN1281V	PN0278W PN0278 PN0224 PN0340W PN0160W PN0108W		PN0035W FN0538 PN0394
05.98~06.03	2500	AHY	T4	RN1389V RN1281V	PN0160W PN0278 PN0340W PN0108W PN0278W PN0224		FN0538 PN0035W
05.98~04.99	2500	AJT	T4	RN1389V RN1281V	PN0160W PN0340W PN0278 PN0278W PN0224		PN0035W FN0538
08.96~06.03	2500	APL	T4	RN1389V RN1281V	PN0278W PN0278 PN0224 PN0340W PN0160W PN0108W		PN0035W FN0538 PN0394
01.96~06.03	2500	AVT	T4	RN1389V RN1281V	PN0278 PN0340W PN0160W PN0108W PN0278W PN0224		FN0538 PN0035W PN0394
09.95~01.96	2500	AYC	T4	RN1053 RN1281V RN1389V	PN0278 PN0340W PN0160W PN0266 PN0108W PN0278W PN0224		PN0394 PN0035W FN0538
05.98~06.03	2500	AYY	T4	RN1281V RN1389V	PN0108W PN0278 PN0278W PN0160W PN0224 PN0340W		PN0035W FN0538
11.95~01.96	2800	AES	T4	RN1053 RN1295V RN1281V RN1389V	PN0278 PN0224 PN0266 PN0108W PN0340W PN0160W PN0278W		FN0538 PN0394 PN0035W
