ROTOR DISC » RN1217V

RN1217V

Specification

Type
Vented
Disc Thickness (Max)
24
Num. of holes
6
Height
45.2
Centering Diameter
87
Pitch Circle Ø
108
Front/Rear
Front
Outter Ø
314
Drum Ø:
136
Structure Material
G3000
Disc Thickness (Min)
22.4

Cross Reference

MITSUBISHI
MB699716
MITSUBISHI
MR249205
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Challenger

08.97~09.01 3500 6G74 K99W RN1217VRN1297V PN3233 RN1119 PN3391 FN0568

MITSUBISHI   »   L200

01.96~05.03 2400 4G64 K75T RN1297VRN1217V PN2824PN3369PN3808PN3233 DN1338 FN6718
01.96~01.07 2500 4D56 K74T RN1217V PN3808 DN1338 FN6718
01.96~12.07 2500 4D56-T K74T RN1217VRN1297V PN3369PN3233PN2824PN3808 DN1338 FN6718

MITSUBISHI   »   Montero Sport

09.96~07.03 3000 6G72 K96W RN1217V PN3233 RN1119 PN3391 FN0568
09.96~08.04 3000 6G72 K96W US RN1217V PN3233 RN1119 PN3391 FN0568

MITSUBISHI   »   Pajero

10.90~05.97 2500 4D56-T V24W RN1217VRN1297V PN3233PN3172 RN1119 PN3280 FN0568
04.91~07.00 3500 6G74 V45W RN1297VRN1217V PN3233 RN1119 PN3280 FN0568

MITSUBISHI   »   Pajero / Montero

12.90~04.04 2800 4M40-T V26W# RN1217V PN3233 RN1119 PN3280 FN0568

MITSUBISHI   »   Pajero / Montero Sport

08.98~02.09 2500 4D56 K94W RN1217V PN3233 RN1119 PN3391 FN0568

MITSUBISHI   »   Shogun

12.90~04.04 2800 4M40-T V26W# RN1217V PN3233 RN1119 PN3280 FN0568
10.90~10.99 3000 6G72 V23 RN1217VRN1297V PN3233 RN1119 PN3280 FN0568
04.91~07.00 3500 6G74 V45W RN1217VRN1297V PN3233 RN1119 PN3280 FN0568
