ROTOR DISC » RN1064V

RN1064V

Specification

Type
Vented
Disc Thickness (Max)
18
Num. of holes
4
Height
45
Centering Diameter
55
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
235
Hole Ø:
13
Disc Thickness (Min)
16.5
Drum Ø:
124
Structure Material
G3000

Cross Reference

BENDIX
561871B
MAZDA
NA013325A
MAZDA
NA013325X
MAZDA
NA013325XA
MAZDA
NA013325XC
MAZDA
NA013325XD
MAZDA
SA013325X
OEM
B4583325XD
OEM
B5Y23325XC
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MAZDA   »   323

04.94~07.98 1300 B3 BA1 RN1064V PN5232 FN3385
01.88~09.93 1300 B3 BW RN1064V PN5232 FN3358FN3385
04.94~07.98 1500 Z5-DE BA1 RN1064V PN5232 PN5365FN3385
06.89~05.94 1600 B6 BG RN1315VRN1064V PN5232 FN3385FN3373
06.89~05.94 1700 PN BG RN1064V PN5232 FN3385
06.89~05.94 1800 BP BG RN1064VRN1315V PN5230PN5232 PN5198FN3385

MAZDA   »   323F

04.94~07.98 1300 B3 BA1 RN1064V PN5232 DN1398 FN3385
06.89~05.94 1600 B6 BG RN1315VRN1064V PN5232 FN3373FN3385

MAZDA   »   MX-5

01.89~01.98 1600 B6 NA RN1064V PN5253PN5364 PN5365PN5198
