ROTOR DISC » RN2156
Specification
Type
Solid
Outter Ø
282
Num. of holes
5
Disc Thickness (Max)
9
Disc Thickness (Min)
7.5
Height
61
Centering Diameter
64.1
Pitch Circle Ø
114.3
Drum Ø:
169.7
Front/Rear
Rear
Structure Material
G3000
Hole Ø:
12.7
Cross Reference
HONDA
42510-SCP-W00
HONDA
42510-SLJ-010
HONDA
42510-SLJ-020
HONDA
42510-SZ3-900
HONDA
42510-SZ3-J00
HONDA
42510-TAA-J00
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.03~12.08 | 2000 | K20A6 | EURO | RN1405V | PN8125PN8465 | RN2156 | PN8109PN8398 | FN0570 |
| 01.06~12.08 | 2000 | K20Z2 | EURO | RN1405VRN1204V | PN8125 | RN2156 | PN8398 | FN0570 |
| 04.03~12.08 | 2200 | N22A1 | CN2 | RN1204V | PN8125 | RN2156 | PN8397 | FN0570 |
| 01.04~12.08 | 2200 | N22A1 | CN2 | RN1204V | PN8125 | RN2156 | PN8397 | |
| 03.03~12.08 | 2400 | K24A3 | EURO | RN1204V | PN8125 | RN2156 | PN8397 | FN0663 |
| 01.09~12.10 | 2400 | K24Z3 | EURO | RN1204V | PN8125 | RN2156 | PN8397 | FN0570 |
| 11.02~12.08 | 2000 | K20A | CM1 | RN1218V | PN8465 | RN2156 | PN8397 | FN0570 |
| 11.02~01.09 | 2400 | K24A | CM2 JPN | RN1218VRN1413V | PN8465 | RN2156 | PN8397 | FN0570 |
| 11.02~12.09 | 2400 | K24A | CM3 | PN8465 | RN2156 | PN8397 | FN0570 |
| 09.16~ | 1500 | LEB | GB8 | RN2155V | PN8811 | RN2156 | PN8807 | FN0570 |
| 09.16~ | 1500 | LEB-H1 | GB7 | RN2155V | PN8811 | RN2156 | PN8807 |
| 04.15~10.21 | 1500 | L15B | RP1 | RN1218V | PN28005 | RN2156 | PN8807 | FN0570 |
| 05.05~10.09 | 2000 | K20 | RG1 JPN | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
| 05.05~10.09 | 2000 | K20 | RG2 | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
| 04.01~10.05 | 2000 | K20A | RF3 | RN1218V | PN8254 | RN2156 | PN8397PN8398 | FN0570 |
| 04.01~05.05 | 2000 | K20A | RF4 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
| 06.03~05.05 | 2000 | K20A | RF5 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
| 06.03~05.05 | 2000 | K20A | RF6 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
| 11.07~01.10 | 2000 | K20Z2 | RG1 RHD | PN8465 | RN2156 | PN8506 | FN0570 | |
| 10.09~04.15 | 2000 | R20A | RK1 JPN | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK2 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK3 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK4 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK5 JPN | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 01.13~04.15 | 2000 | R20A1 | RK1 GR | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 05.05~10.09 | 2400 | K24 | RG3 | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
| 06.03~05.05 | 2400 | K24A | RF7 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
| 06.03~05.05 | 2400 | K24A | RF8 | RN1218V | PN8254 | RN2156 | PN8397 | FN0570 |
| 05.05~10.09 | 2400 | K24A | RG4 JPN | RN1218V | PN8465 | RN2156 | PN8506 | FN0570 |
